High Voltage PROTECTION!

Diamond Plate Military Switchboard Matting

Non Conductive Safety Matting for use around high voltage power sources. Outstanding selection AND Pricing, fully Compliant, custom cut lengths and full rolls!


208-AS Diamond Plate High Voltage Switchboard Safety Matting Helps Isolate a Technician from High Voltages

Our Diamond plate switchboard matting is designed to PROTECT technicians from high voltages around highly energized equipment and switchboards.

Without switchboard matting exposure to electrical power sources can flow through the technician and in many cases ground out through the persons shoes to the semi-conductive concrete beneath their feet.

Our 208-AS high voltage switchboard matting meets the tough military specifications of 15562-G Type II. It's highly resistant to ozone, acids, flames and a variety of industrial chemicals used in industry.

208's unique diamond plate textured top surface provides outstanding slip resistance. It's easy to keep clean yet robust and designed to provide years worth of reliable protection from high voltage events.

Designed for hard surface floor applications.
30,000 volts, 15,000 volts AC Proof Test
Ozone, acid and flame resistant
Designed to meet strict military standards
Color: Black
Thickness: 3/16"
Meets all test methods and property requirements of military specification 15562-G, Amend .3, Type II. Note: Certificate of compliance available upon request when you place your order.

FREE SHIPPING on all full rolls of this Electrically INSULATIVE Switchboard Matting going to our Clients in the Continental U.S.A. Details Apply. Note: Please allow up to four weeks for us to ship this product

Part Number: 208-AS

Pre Cut Pricing and Full 75' long rolls:
3' x 4'	$161.00	only). Need another length not shown? Simply call us for pricing and to place your order. Click here to purchase, use the drop down to select your size Free shipping on all full rolls!
3' x 6'	$239.00
3' x 8'	$317.00
3' x 10'	$395.00
3' x 12'	$473.00
3' x 20'	$785.00
3' x 30'	$1,175.00
3' x 40'	$1,565.00
3' x 50'	$1,955.00
Save! 3' x 75' Full Roll	$2,440.80

Sales Associates!

To use the old school precut calculator please click here

Terms and conditions of free shipping program
