Anti Static Tiles / Options
in ESD Floor Tile!
Powerful Performance,
Permanent Conductivity, Outstanding Value!
WHY ANTI STATIC VINYL FLOOR TILES?
ESD tiles were first invented by Vinyl
Products Incorporated of Sheboygan Wisconsin in the United States of America around 1959. Since that time Anti Static Floor
Tiles have grown to be a common choice in esd flooring for static control.
These original tiles relied on a variegated (veiny) encapsulated conductive
carbon pattern extending throughout the thickness of the tile to provide
electrical conductivity. Many tiles still rely on this variegated pattern
but newer non variegated tiles are quickly gaining popularity with
the Architectural Community and design selective clientele. ESD tiles are fairly easy to install but
directions for installation must be followed meticulously. They provide
excellent color options and consistent long term electrical properties. All
ESD tiles are fairly easy to replace (should the tiles become worn of
damaged). But remember Dye lots can change! We recommend ordering a few
extra tiles with your initial order for "attic Stock."
CONSIDERATIONS WHEN MAKING YOUR SELECTION!
All installed ESD Tile flooring has seams! Tile to tile
conductivity is bridged via the use of specialty conductive adhesives. No
matter how tightly tiles fit together seams and deviations are slightly
apparent in the finished install. This nuance is more apparent with high
gloss, thicker (1/8 inch) tiles and tile installations backlit by open sunny
windows
photo .
ESD tiles are fairly easy to install but installation instructions must be
followed meticulously. Unlike most standard (VCT style) floor tiles, ESD
tiles are non porous. Hence, even relatively low concrete emissions are the
number one cause of esd tile flooring failure. Pre test your concrete slab
for vapor emissions prior to use of any vinyl flooring product. Testing for
vapor emissions is easy and well worth the effort. Employee Safety
Tip: Consider slip resistance when making your selection of esd flooring
tiles. High gloss esd tiles can be very
slick when wet. We've conveniently listed tiles with outstanding slip
resistance in the following selections
THE MOST POPULAR ESD TILES FOR STATIC CONTROL.
ElectraTile
Anti Static ESD Tile - Value oriented, high
shine, meets latest ANSI
specs micro edged,
excellent
quality, great pricing. Variegated (VPI style) pattern Great
availability! 1' x 1' and 2' x 2' x 1/8 inch thick. Static
conductive, beautiful
colors. Installed cost
(including materials and labor) about $4.00 to $5.00 per square foot.*
 NEW!!!
ElectraFloor Titanium Series ESD Floor Tiles - Same
time tested performance as our Titanium ESD sheet goods NOW
available in a Tile! Non variegated, awesome aesthetics! Slip
resistant, 2' x 2' tiles. An industry
exclusive ONLY at United SCP! Installed cost (including
materials and labor) about $5.50 per square foot.*
 ElectraFloor
Diamond Series ESD Vinyl Tile
- Outstanding value, proven track record,
medium gloss. Fair slip resistance (when wet), good charge decay and
electrical consistency. Multiple designer colors, typically stocked.
ESD Conductive OR Static Dissipative. 2' x 2' tiles. Installed
cost (materials and labor) about $5.50 per square foot.*
 VPI
ESD Tile - Outstanding high gloss, excellent dimensional stability, extensive color selections. Heat
treated to eliminate long term shrinkage. Variegated. Multiple sizes. Available in both
Static Dissipative OR Static Conductive. Made
start to finish in the United states of America! Installed cost
about $6.00 per square foot.*
 Forbo
ESD Tiles - High quality pure vinyl devoid of cheap clay fillers and binders.
Proprietary conductive grid work backing for optimum electrical
consistence. Time tested and reliable manufacturer. Fabulous
color selection. Available in static conductive AND static
dissipative. Installed cost (materials and labor) about $6.50
per square foot.*
*NOTE: Installed cost based on nationwide averages of areas of
3,000 square feet. Installed cost may vary depending on your
location and the actual size and complexity of your
installation.
WHY UNITED FOR ANTI STATIC FLOOR TILES!
Today's choices in ESD flooring range from the obscure to the absurd. ESD
rubber (the product with such low compressive strength that even pallet jack
traffic destroys it), thick set esd epoxy (customers comments: "I can't
believe it's so easy to scratch"), stainless steel plates??? Unlike our "competitors" that simply sell static
control floor materials as a sideline
(and wish you good luck;) we've specialized in ESD flooring
since 1993, having supplied, installed and certified MILLIONS of square feet
in a variety of industries and environments.
At United SCP we understand that in many cases the
success of your esd program depends on the reliable performance of your esd
flooring. Your flooring is interactive, it's part of a bigger picture. It must
perform in concert with ESD chairs, carts, shelving, trolleys
and personnel. In the past (just several years ago;) choices for quality
esd flooring (and what the floors had to achieve) were limited, now
the selections (and the new requirements of ANSI ESD S2020-2007 are extensive.
Not only do we provide the largest
selection of ESD flooring on the market we
provide unmatched engineering and installation skills
to help successfully match your
needs with the appropriate materials. We provide award winning 24/7
Tech support for our customers and their installers. Provide help in
certifying the electrical conductivity to the latest standards and are there
for our client if and when they need us! Our goal is simple and we do it well
- We provide
flawless, compliant, long term static control flooring and industry
leading engineering and installation support to back up our products!
CONTACT
UNITED STATIC CONTROL PRODUCTS!
United Static Control Products
P.O.B. 19252, 4878 Lake View Circle
Colorado City, CO 81019
United States of America
Phone: 719 676
3928 Fax: 719 676 3929
24/7
Tech Support (customers only)
719
676 3928 (option 8)
Major Credit
Cards Accepted
ESD
Flooring,
Mats, Chemicals,
ESD Ionizers, and
Expertise
United SCP Tames the Static Beast BEFORE it Takes Another Byte
This page last updated on
02/07/2010
|
|
|
CUSTOMERS
Interested in Anti Static Tile Also Chose:
United
SCP's ESD Tile Installation Services
- Experienced Installers. High
level security clearance. On Time high quality project
completion with No Headaches and NO surprises! Full on
site electrical certification to latest industry accepted
standards at no charge with your installation.
ESD
Conductive Floor Paint and Sealer System
- Installed cost less than $2.00
per square foot! Outstanding aesthetics, high shine yet
excellent slip resistance. Compliant to latest ANSI / ESD
Standards. 10 Year life expectancy!
Anti
Static Floor finish - Protects esd hard surface flooring, makes scuff
marks easy to remove! 2 thin coats maintains compliant
conductivity!
ESD
Conductive Chair Mats -
Protect that beautiful new floor from chair caster wear. Compliant to the latest
ANSI ESD requirements!
ESD
Heel Straps - Outstanding quality and best price in the
Nation. and IN STOCK!
TECH
CORNER!
How to maintain
an esd conductive floor - Reduce maintenance cost, maintain
conductivity. Care and feeding of your new esd floors. All anti-static
floors need a little TLC sometimes!
tiles for static control
flooring
|
|
